₹111,000.00 Original price was: ₹111,000.00.₹50,387.00Current price is: ₹50,387.00.
Return Within 30 Days
Contact 24 Hours Day
Safe &Secure Payment
Shipping all over India
General Specifications |
|
Platform |
Desktop |
Market Segment |
Enthusiast Desktop |
Product Family |
AMD Ryzen™ Processors |
Product Line |
AMD Ryzen™ 9 Desktop Processors |
AMD PRO Technologies |
No |
Consumer Use |
Yes |
Regional Availability |
Global |
Former Codename |
“Raphael AM5” |
Architecture |
“Zen 4” |
# of CPU Cores |
16 |
Multithreading (SMT) |
Yes |
# of Threads |
32 |
Max. Boost Clock |
Up to 5.7GHz |
Base Clock |
4.5GHz |
L1 Cache |
1MB |
L2 Cache |
16MB |
L3 Cache |
64MB |
Default TDP |
170W |
Processor Technology for CPU Cores |
TSMC 5nm FinFET |
Processor Technology for I/O Die |
TSMC 6nm FinFET |
CPU Compute Die (CCD) Size |
71mm² |
I/O Die (IOD) Size |
122mm² |
Package Die Count |
3 |
Unlocked for Overclocking |
Yes |
AMD EXPO™ Memory Overclocking Technology |
Yes |
Precision Boost Overdrive |
Yes |
Curve Optimizer Voltage Offsets |
Yes |
AMD Ryzen™ Master Support |
Yes |
CPU Socket |
AM5 |
Supporting Chipsets |
|
CPU Boost Technology |
Precision Boost 2 |
Instruction Set |
x86-64 |
Supported Extensions |
AES, AMD-V, AVX, AVX2, AVX512,FMA3, MMX(+), SHA, SSE, SSE2,SSE3, SSE4.1, SSE4.2, SSE4A,SSSE3, x86-64 |
Thermal Solution (PIB) |
Not included |
Max. Operating Temperature (Tjmax) |
95°C |
*OS Support |
|
Connectivity |
|
USB Type-C® Support |
Yes |
Native USB 3.2 Gen 2 (10Gbps) Ports |
4 |
Native USB 3.2 Gen 1 (5Gbps) Ports |
0 |
Native USB 2.0 (480Mbps) Ports |
1 |
Native SATA Ports |
0 |
PCI Express® Version |
PCIe® 5.0 |
Native PCIe® Lanes (Total/Usable) |
28/24 |
Additional Usable PCIe Lanes from Motherboard |
|
NVMe Support |
Boot, RAID0, RAID1, RAID10 |
Memory Channels |
2 |
Max. Memory |
128GB |
System Memory Subtype |
UDIMM |
Max Memory Speed |
|
ECC Support |
Yes (Requires mobo support) |
Graphics Capabilities |
|
Integrated Graphics |
Yes |
Graphics Model |
AMD Radeon™ Graphics |
Graphics Core Count |
2 |
Graphics Frequency |
2200 MHz |
USB Type-C® DisplayPort™ Alternate Mode |
Yes |
Product IDs |
|
Product ID Boxed |
100-100000514WOF |
Key Features |
|
Supported Technologies |
|
Warrenty; |
3 Years |
