Specification
Compatibility |
Intel : LGA2066/2011-v3/2011/LGA1200/1151/1150/1155/1366 AMD : TR4/AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1 |
Radiator Dimensions |
282×120×27 mm |
Radiator Material |
Aluminum |
Net Weight |
1617 g |
Tube length |
380 mm |
Pump Dimensions |
93.7×93×85 mm |
Pump Speed |
2200 RPM±10% |
Pump Noise |
17.8 dB(A) |
Pump Connector |
3-pin |
Pump Rated Voltage |
12 VDC |
Pump Rated Current |
0.13 A |
Pump Power Consumption |
1.56 W |
Fan Dimensions |
120×120×25 mm |
Fan Speed |
500~1800 RPM±10% |
Fan Airflow |
69.34 CFM |
Fan Air Pressure |
2.42 mmAq |
Fan Noise |
≤30 dB(A) |
Fan Connector |
4-pin PWM |
Bearing Type |
Hydro Bearing |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.17 A |
Fan Power Consumption |
2.04 W |
LED Type |
Addressable RGB LED |
LED Connector |
3-pin(+5V-D-G) |
LED Rated Voltage |
5 VDC |
LED Power Consumption |
0.9 W(PUMP)/4.8 W(FAN×2) |
Warranty |
3 Years |
