Product Collection
|
10th Generation Intel® Core™ i7 Processors
|
Code Name
|
Products formerly Comet Lake
|
Vertical Segment
|
Desktop
|
Processor Number
|
i7-10700K
|
Lithography
|
14 nm
|
Use Conditions
|
PC/Client/Tablet
|
Performance Specifications
|
Cores
|
8
|
Threads
|
16
|
Processor Base Frequency
|
3.80 GHz
|
Max Turbo Frequency
|
5.10 GHz
|
Cache
|
16 MB Intel® Smart Cache
|
Bus Speed
|
8 GT/s
|
Intel® Turbo Boost Max Technology 3.0 Frequency
|
5.10 GHz
|
Intel® Turbo Boost Technology 2.0 Frequency
|
5.00 GHz
|
TDP
|
125 W
|
Configurable TDP-down Frequency
|
3.50 GHz
|
Configurable TDP-down/td>
|
95 W
|
Supplemental Information
|
Embedded Options Available
|
No
|
Memory Specifications
|
Max Memory Size (dependent on memory type)
|
128 GB
|
Memory Types
|
DDR4-2933
|
Max Memory Channels
|
2
|
Max Memory Bandwidth
|
45.8 GB/s
|
ECC Memory Supported
|
No
|
Processor Graphics
|
Processor Graphics
|
Intel® UHD Graphics 630
|
Graphics Base Frequency
|
350 MHz
|
Graphics Max Dynamic Frequency
|
1.20 GHz
|
Graphics Video Max Memory
|
64 GB
|
4K Support
|
Yes, at 60Hz
|
Max Resolution (HDMI 1.4)
|
4096×2160@30Hz
|
Max Resolution (DP)
|
4096×2304@60Hz
|
Max Resolution (eDP – Integrated Flat Panel)
|
4096×2304@60Hz
|
DirectX Support
|
12
|
OpenGL Support
|
4.5
|
Intel® Quick Sync Video
|
Yes
|
Intel® InTru™ 3D Technology
|
Yes
|
Intel® Clear Video HD Technology
|
Yes
|
Intel® Clear Video Technology
|
Yes
|
Displays Supported
|
3
|
Device ID
|
0x9BC5
|
Expansion Options
|
Scalability
|
1S Only
|
PCI Express Revision
|
3.0
|
PCI Express Configurations
|
Up to 1×16, 2×8, 1×8+2×4
|
Max PCI Express Lanes
|
16
|
Advanced Technologies
|
Intel® Optane™ Memory Supported
|
Yes
|
Intel® Thermal Velocity Boost
|
No
|
Intel® Turbo Boost Max Technology 3.0
|
Yes
|
Intel® Turbo Boost Technology
|
2.0
|
Intel® vPro™ Platform Eligibility
|
Yes
|
Intel® Hyper-Threading Technology
|
Yes
|
Intel® Virtualization Technology (VT-x)
|
Yes
|
Intel® Virtualization Technology for Directed I/O (VT-d)
|
Yes
|
Intel® VT-x with Extended Page Tables (EPT)
|
Yes
|
Intel® Transactional Synchronization Extensions
|
No
|
Intel® 64
|
Yes
|
Instruction Set
|
64-bit
|
Instruction Set Extensions
|
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
|
Idle States
|
Yes
|
Enhanced Intel SpeedStep® Technology
|
Yes
|
Thermal Monitoring Technologies
|
Yes
|
Intel® Identity Protection Technology
|
Yes
|
Intel® Stable Image Platform Program (SIPP)
|
Yes
|
Security & Reliability
|
Intel® AES New Instructions
|
Yes
|
Secure Key
|
Yes
|
Intel® Software Guard Extensions (Intel® SGX)
|
Yes with Intel® ME
|
Intel® OS Guard
|
Yes
|
Intel® Trusted Execution Technology
|
Yes
|
Execute Disable Bit
|
Yes
|
Intel® Boot Guard
|
Yes
|
Package Specifications
|
Sockets Supported
|
FCLGA1200
|
Max CPU Configuration
|
1
|
Thermal Solution Specification
|
PCG 2015D
|
TJUNCTION
|
100°C
|
Package Size
|
37.5mm x 37.5mm
|
Warranty
|
3 Years
|
