Intel® Core™ Ultra 9 Processor 285K (36M Cache- up to 5.70 GHz) | |
Essentials | |
Product Collection | Intel® Core™ Ultra Processors (Series 2) |
Code Name | Products formerly Arrow Lake |
Vertical Segment | Desktop |
Processor Number | 285K |
Overall Peak TOPS (Int8) | 36 |
CPU Specifications | |
Total Cores | 24 |
# of Performance-cores | 8 |
# of Efficient-cores | 16 |
Total Threads | 24 |
Max Turbo Frequency | 5.7 GHz |
Intel® Thermal Velocity Boost Frequency | 5.7 GHz |
Intel® Turbo Boost Max Technology 3.0 Frequency ‡ | 5.6 GHz |
Performance-core Max Turbo Frequency | 5.5 GHz |
Efficient-core Max Turbo Frequency | 4.6 GHz |
Performance-core Base Frequency | 3.7 GHz |
Efficient-core Base Frequency | 3.2 GHz |
Cache | 36 MB Intel® Smart Cache |
Total L2 Cache | 40 MB |
Processor Base Power | 125 W |
Maximum Turbo Power | 250 W |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
AI Software Frameworks Supported by CPU | OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN |
CPU Lithography | TSMC N3B |
Supplemental Information | |
Marketing Status | Launched |
Launch Date | Q4’24 |
Embedded Options Available | No |
Use Conditions | PC/Client/Tablet | Workstation |
Datasheet | View now |
Memory Specifications | |
Max Memory Size (dependent on memory type) | 192 GB |
Memory Types | Up to DDR5 6400 MT/s |
Maximum Memory Speed | 6400 MHz |
Max # of Memory Channels | 2 |
ECC Memory Supported ‡ | Yes |
GPU Specifications | |
GPU Name‡ | Intel® Graphics |
Graphics Base Frequency | 300 MHz |
Graphics Max Dynamic Frequency | 2 GHz |
GPU Peak TOPS (Int8) | 8 |
Graphics Output | DP2.1 UHBR20 | HDM2.1 FRL 12GHz | eDP1.4b |
Xe-cores | 4 |
Max Resolution (HDMI)‡ | 4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL) |
Max Resolution (DP)‡ | 8K @ 60Hz |
Max Resolution (eDP – Integrated Flat Panel)‡ | 4K @ 60Hz |
DirectX* Support | 12 |
OpenGL* Support | 4.5 |
OpenCL* Support | 3 |
Intel® Quick Sync Video | Yes |
# of Displays Supported ‡ | 4 |
Device ID | 0x7D67 |
Intel® Deep Learning Boost (Intel® DL Boost) on GPU | Yes |
