Specification
GENERAL | |
---|---|
Brand | TVS |
Model | BS-L100N |
Color | Black |
Type | Barcode Scanner |
FEATURES | |
---|---|
Light Source
|
650 nm visible laser diode |
Precision Scan Angle
|
5mil |
Pitch
|
±55° @0° Rolland0° Skew |
Roll
|
±25° @0° Pitch and0° Skew |
Skew
|
±75° @0° Rolland0° Pitch |
Minimum Symbol Contrast
|
25% |
Scan Rate
|
300 scans per second
|
Interface
|
RS-232, USB |
Notification
|
Beep and LED indicator |
Power Adaptor
|
Output: DC5V, 1.5A Input: AC100~240V, 50~60Hz |
Current Operating Current
|
100 mA |
Standby Current
|
20 mA |
Static Discharge
|
±8KV (Contact discharge); ±15KV (Air discharge) |
Drop
|
1.5m drop to concrete |
Sealing
|
IP54 |
DIMENSIONS | |
---|---|
Weight | 105g |
Package Dimensions | 156 x 95 x 71 mm |
WARRANTY | |
---|---|
Warranty Period | 1 Year Warranty |
Warranty Type | Manufacturer Limited |
